自動上下料機可以實現不同尺寸材料抓取，材料加熱后可以實現自動上料及成品下件，實現無人化生產，大大節約人工。
The automatic upper and bottom feeder can be used to grab the different dimensions, and the material can be heated and the automatic material and finished product can be realized, and the production of unmade production is greatly saved.
自動上下料機可以實現不同尺寸材料抓取，材料加熱后可以實現自動上料及成品下件，實現無人化生產，大大節約人工。
The automatic upper and bottom feeder can be used to grab the different dimensions, and the material can be heated and the automatic material and finished product can be realized, and the production of unmade production is greatly saved.
序號 S/N | 型號 Model | 最大材料 Maximum material | X軸行程 X-axis travel | X軸速度 X-axis velocity | Y軸行程 Y-axis travel | Y軸速度 Y-axis velocity | Z軸行程 Z-axis travel | Z軸速度 Z-axis velocity | 有效負載 Payload |
1 | HW-AUD-500015 | 1800*2700 | 5000 | 0-30m/min | / | / | 1500 | 0-8m/min | 40KG |
2 | HW-AUD-550015 | 2100*3000 | 5500 | 0-30m/min | / | / | 1500 | 0-8m/min | 55KG |
3 | HW-AUD-650015 | 3000*3000 | 6500 | 0-30m/min | / | / | 1500 | 0-8m/min | 65KG |
4 | HW-AUM-500015 | 1800*2700 | 5000 | 0-30m/min | 1000 | 0-10m/min | 1500 | 0-8m/min | 40KG |
5 | HW-AUM-550015 | 2100*3000 | 5500 | 0-30m/min | 1200 | 0-10m/min | 1500 | 0-8m/min | 55KG |
6 | HW-AUM-650015 | 3000*3000 | 6500 | 0-30m/min | 1500 | 0-10m/min | 1500 | 0-8m/min | 65KG |
